100 ton Stretching and Detwisting Machine, O/No. 63560, c.1964

Order 63560 for High Duty Alloys, Workington, c.1964

D7338/14/5/14/6120
Gloucestershire Archives
D7338/14/5/14/6122
Gloucestershire Archives
D7338/14/5/14/6123
Gloucestershire Archives
D7338/14/5/14/6124
Gloucestershire Archives
D7338/14/5/14/6125
Gloucestershire Archives

Click on a photograph to enlarge an image.

Click on the hyperlink to see a brief Engineering Specification for this machine.

Click on the hyperlink to see other Notable Orders from the 1960s

If you remember designing, machining, fitting, installing, maintaining, or working with this machine please share your memories at the bottom of the page by clicking on the words Add a comment about this page.

Comments about this page

  • I, and my section, engineered this machine from a design by (cannot remember his name). I do remember a gentleman coming from the customer to examine this in the workshop prior to delivery. There were four jaws to grip the work piece for stretching. These were operated by a pneumatic system.

    By Herbert Hindle. C.Eng M.I.E.T (14/08/2015)
  • Hi Bert!  Many thanks for the information. Was the design engineer Eric Penning by any chance?  Interesting that the grips were pneumatically operated – was this because pneumatic cylinders would be more forgiving (shock absorbing) in the event of a section breakage?    John B

    By John Bancroft (14/08/2015)
