Model of a Shell Forging Plant, c.1957

Subsequently ordered for the Royal Ordnance Factory (R.O.F.) Birtley, Tyne & Wear

D7338/14/5/9/5295
Gloucestershire Archives
D7338/14/5/9/5296
Gloucestershire Archives
D7338/14/5/9/5297
Gloucestershire Archives
D7338/14/5/9/5398
Gloucestershire Archives

This wooden model was probably made as a sales aid at the tendering stage of a contract for the supply of a complete shell manufacturing plant.

Fielding & Platt was awarded a major contract for the supply of hydraulic presses and ancillaries including the air/water hydraulic accumulator station and pumps necessary to drive the presses.

Click on a photograph to enlarge an image.

Click on the hyperlink to see the 1000 ton Pierce Press.

Click on the hyperlink to see the 400 ton Drawing Press.

Click on the hyperlink to see the Pumps and Accumulator Station.

If you had any involvement in designing, making and assembling any of the Fielding & Platt models or know the current whereabouts of any models that may have survived, please share your memories at the bottom of the page by clicking on the words Add a comment about this page.
