Model of a 1500 ton Pull - Down Forging Press, c.1958

Subsequently ordered by Daniel Doncaster Ltd., Sheffield

D7338/14/5/9/5264
Gloucestershire Archives
D7338/14/5/9/5264A
Gloucestershire Archives
D7338/14/5/9/5270
Gloucestershire Archives
D7338/14/5/9/5270A
Gloucestershire Archives

The first of two models of this press, made mainly from wood and complete with a sliding toolpost and tools, this model ably illustrates the amount of equipment that resided below floor level.  The real press is still in operation!

Click on a photograph to enlarge an image.

Click on the hyperlink to see photographs of the real thing!
